UNI ADAPTER – FROM 3 CONNECTIONS TO 4 CONNECTIONS

(Multiple Output – Modular Transition – Compatible with Hydraulic/Pneumatic Systems)

This special type UNI adapter is used to provide a transition from 3 connection ports to 4 connections in hydraulic or pneumatic systems. It is generally preferred when system expansion is required at pump outlets, valve inlets, or manifold connections. Thanks to its modular structure, it offers easy integration into both fixed and mobile systems. With aluminum or steel body options, it provides a high-pressure resistant and leak-proof solution.

Technical Specifications

Adapter type: UNI transition connection adapter
Input connection: 3 ports (G1/2″ – G3/4″)
Output connection: 4 ports (G1/2″ – G3/4″)
Body material: Aluminum (standard) / Steel (optional)
Maximum working pressure: 250 bar (hydraulic) / 12 bar (pneumatic)
Sealing: NBR / Viton seal options
Mounting type: Threaded / flanged / clamped
Standards: Compatible with DIN 2353 / ISO 8434-1
Optional features:
O-ring supported sealing
Color-coded outputs
Compact body design

Advantages

Provides system expansion by enabling transition from 3 connections to 4 connections
Easy integration into different systems thanks to its modular structure
Safe operation with high pressure resistance
Lightweight and corrosion-resistant thanks to aluminum body
Leak-proof sealing structure
Ideal for use in mobile and fixed systems
Fully compatible with DIN and ISO connection standards
Maintenance-friendly design and easy access
Flexible solution for valve, pump, manifold, and sensor connections
